The Master pump is a drainage pump with a high performance-weight ratio, and it shares all important features and benefits with the other models, resulting in the lowest cost per cubic meter pumped.
The drainage range of pumps drain water, not your wallet! The revolutionary hydraulic design ensures high wear resistance and dramatically reduces performance drop due to long time wear.
Available in both 50hz and 60hz models.
| Technical Data | N | H | SH |
|---|---|---|---|
| Discharge connection | 6″ | 4″ | 3″ |
| Rated output | 10 kW | 10 kW | 10 kW |
| Max power consumption | 11.7 kW | 11.7 kW | 11.7 kW |
| Rated current at 400 V | 21 A | 21 A | 19 A |
| Rated current at 500 V | 15 A | 15 A | 15 A |
| Shaft speed | 2855 RPM | 2855 RPM | 2855 RPM |
| Strainer holes | ∅ 10 mm | ∅ 10 mm | ∅ 10 mm |
| Weight | 80 kg | 80 kg | 98 kg |
| Height | 832 mm | 832 mm | 887 mm |
| Width | ∅ 346 mm | ∅ 346 mm | ∅ 346 mm |
