The Maxi pump has proven to be the ideal pump for heavy duty drainage applications in all kinds of segments. Be it Construction, Mining or Industrial applications, the robust and reliable design combined with the ease-of-maintenance make it the pump of choice for hundreds of customers around the world.
Available in both 50hz and 60hz models.
| Technical Data | L | N | H |
|---|---|---|---|
| Discharge connection | 8″ | 8″ | 4″ |
| Rated output | 30 kW | 37 kW | 37 kW |
| Max power consumption | 33 kW | 41 kW | 41 kW |
| Rated current at 400 V | 57 A | 65 A | 65 A |
| Rated current at 500 V | 45 A | 52 A | 52 A |
| Shaft speed | 1465 RPM | 2950 RPM | 2950 RPM |
| Strainer holes | ∅ 12 mm | ∅ 12 mm | ∅ 12 mm |
| Weight | 285 kg | 285 kg | 285 kg |
| Height | 1345 mm | 1345 mm | 1345 mm |
| Width | ∅ 510 mm | ∅ 510 mm | ∅ 510 mm |
