The Minex pump is the smallest model in the drainage range, but it shares all important features and benefits with the larger models, resulting in the lowest cost per cubic metre pumped.
The drainage range of pumps drain water, not your wallet!
The revolutionary hydraulic design ensures high wear resistance and dramatically reduces performance drop due to long time wear.
Available in both 50hz and 60hz models.
| Technical Data | Lite | 1~ | 3~ |
|---|---|---|---|
| Discharge connection | 2″ | 2″ | 2″ |
| Rated output | 0.85 kW | 1.4 kW | 1.2 kW |
| Max power consumption | 1.1 kW | 1.7 kW | 1.6 kW |
| Rated current at 230 V | 5.1 A | 7.8 A | 4.7 A |
| Rated current at 400 V | – | – | 2.6 A |
| Shaft speed | 2755 RPM | 2780 RPM | 2470 RPM |
| Strainer holes | ∅ 7.5 mm | ∅ 7.5 mm | ∅ 7.5 mm |
| Weight | 21.5 kg | 25 kg | 21.5 kg |
| Height | 616 mm | 646 mm | 616 mm |
| Width | ∅ 200 mm | ∅ 200 mm | ∅ 200 mm |
