The Minor pump is one of the more popular models in the drainage range, and it shares all important features and benefits with the other models, resulting in the lowest cost per cubic meter pumped. The drainage range of pumps drain water, not your wallet! The revolutionary hydraulic design ensures high wear resistence and dramatically reduces performance drop due to long time wear. The Minor pump is available in two configurations:
Available in both 50hz and 60hz models
| Technical Data | N | H |
|---|---|---|
| Discharge connection | 4″ | 3″ |
| Rated output | 3.7 kW | 3.7 kW |
| Max power consumption | 4.4 kW | 4.4 kW |
| Rated current at 400 V | 7.3 A | 7.3 A |
| Rated current at 500 V | 5.4 A | 5.4 A |
| Shaft speed | 2855 RPM | 2855 RPM |
| Strainer holes | ∅ 10 mm | ∅ 10 mm |
| Weight | 50 kg | 50 kg |
| Height | 768 mm | 768 mm |
| Width | ∅ 286 mm | ∅ 286 mm |
