Based on the same basic design as the drainage pumps, the sludge pumps come into action when the liquid gets dirtier than can be handled by the drainage pumps. The design even permits converting between drainage and sludge models allowing you to adapt the pump according to the varying conditions.
Available in both 50hz and 60hz models.
| Technical Data | N | H |
|---|---|---|
| Discharge connection | 3″ | 3″ |
| Rated output | 5.6 kW | 5.6 kW |
| Max power consumption | 6.6 kW | 6.6 kW |
| Rated current at 400 V | 11 A | 11 A |
| Rated current at 500 V | 8.7 A | 8.7 A |
| Shaft speed | 2895 RPM | 2895 RPM |
| Strainer holes | ∅ 50 mm | ∅ 32 mm |
| Weight | 56 kg | 56 kg |
| Height | 867 mm | 867 mm |
| Width | 460 mm | 430 mm |
| Diameter | ∅ 320 mm | ∅ 320 mm |
