Grindex Slurry Pump: Bravo 900

Electrical submersible slurry pump

Submersible slurry pumps for pumping fluids with abrasive solids

The Bravo 900, our biggest slurry pump, is extremely wear-resistant thanks to the use of Hard-Iron™ and the low shaft speed. Equipped with an agitator to enhance the ‘up-stirring’ capabilities it is a superior quality pump for all kinds of slurry applications.

Available in Explosion Proof version.
Available in both 50hz and 60hz models.

Bravo-900
Discharge connection6″
Rated output70 kW
Max power consumption75 kW
Shaft speed1475 RPM
Rated current at 400 V132 A
Rated current at 500 V102 A
Throughlet36 mm
Max. Liquid Density:
1.7 kg/m3
Max. Liquid Density:
1.7 kg/m3
